Tungsten Alloy Rod in Medical Radiation Shielding

Tungsten alloy rod in medical radiation shielding is high density tungsten alloy rod used for manufacturing radiation protection and shielding components in medical radiological equipment. Based on tungsten (W) with nickel (Ni), iron (Fe), or copper (Cu) as binder phases, it is manufactured through powder metallurgy processes. CTIA’s tungsten alloy rod features high density, excellent radiation shielding performance, high strength, and dimensional stability, providing efficient radiation protection within limited spaces. The material can be processed into medical linear accelerator collimators, rotary shielding components, radioactive source shielding components, and other radiation protection structures, and is widely applied in radiation shielding systems for radiotherapy equipment and nuclear medicine devices.

1. Characteristics of CTIA’s Tungsten Alloy Rod in Medical Radiation Shielding
(1) High-Efficiency Radiation Shielding Performance
With a density of 16.5–18.5 g/cm³, the material provides excellent attenuation capability against X-rays and gamma rays, achieving higher shielding efficiency at the same thickness and enabling compact radiation protection designs for medical equipment.
(2) Environmental Safety
Contains no lead, avoiding contamination risks associated with traditional lead shielding materials and meeting modern medical equipment requirements for environmental protection and safety.
(3) Structural Stability
Maintains stable dimensions under temperature variations and long-term operating conditions due to its high strength and low coefficient of thermal expansion, ensuring reliable shielding performance over extended service periods.
(4) Precision Machining Capability
Supports turning, milling, grinding, and Electrical Discharge Machining (EDM) processes to produce collimators, shielding blocks, and customized radiation protection structures with complex geometries.
(5) Adaptability to Special Environments
Offers W-Ni-Cu (non-magnetic) grades suitable for strong magnetic field environments such as Magnetic Resonance Imaging (MRI) systems, while providing good corrosion resistance for long-term medical equipment operation.

2. Applications of CTIA’s Tungsten Alloy Rod in Medical Radiation Shielding
Processed into radiation shielding components, protective structures, and precision assemblies, CTIA’s tungsten alloy rod is widely used in medical equipment radiation protection systems:
(1) X-Ray Equipment
Used in radiation shielding components and collimation structures of X-ray machines, Digital Radiography (DR) equipment, and other imaging systems to reduce the impact of scattered radiation.
(2) Computed Tomography (CT) Equipment
Applied in X-ray collimators, localized shielding components, and protective structures of CT systems to enhance radiation control performance.
(3) Radiotherapy Equipment
Used in radiation shielding components and shielding structures of Medical Linear Accelerator (LINAC) systems and other radiotherapy equipment to improve operational safety.
(4) Nuclear Medicine Equipment
Applied in radiation shielding components of Positron Emission Tomography (PET), Single Photon Emission Computed Tomography (SPECT), and other nuclear medicine devices to reduce radiation exposure from radioactive sources.
(5) Medical Radiation Protection Devices
Used as high-density shielding components in medical inspection equipment, radiation protection devices, and customized shielding structures to improve overall radiation protection performance.

3. Specifications of CTIA’s Tungsten Alloy Rod in Medical Radiation Shielding
(1) Tungsten Content: 90%–97%
(2) Density: 16.5–18.8 g/cm³
(3) Dimensions: Customizable according to application requirements
(4) Surface Conditions: Ground, precision ground, polished, etc.

CTIA GROUP has specialized in tungsten alloy manufacturing for nearly 30 years, providing customized tungsten alloy rods with various grades, dimensions, and processing conditions. Available grades include 90WNiFe, 92.5WNiFe, 95WNiFe, 97WNiFe, 90WNiCu, 92.5WNiCu, 95WNiCu, 92.5WNiFeMo, and 93WNiFeMo. CTIA’s tungsten alloy rods combine high density, high strength, excellent radiation shielding performance, and precision machining capability to meet the requirements of radiation shielding components in medical imaging, radiotherapy, and nuclear medicine equipment for shielding efficiency, structural stability, and long-term reliability.
